In metal fabrication, most of the total project cost is determined long before the part is cut. Early decisions about material selection, geometry, tooling, bending strategy, welding, and tolerance control can account for as much as 70-80% of the total cost. Once production begins, every design change becomes exponentially more expensive, which is why early engineering support is critical.

By integrating fabrication and engineering, Lock-Ridge Tool identifies and overcomes manufacturability challenges, ensuring every part is designed for manufacturability from the start. This early collaboration between both disciplines eliminates costly surprises, prevents material waste, and streamlines every step from prototype to production.

What Early Engineering Support Delivers

Engineering support helps projects move seamlessly from concept to production by refining designs using real-world manufacturing insights that maximize process efficiency, material yield, and structural integrity. When engineering gets involved early, before prototypes are finalized, every aspect of production becomes more efficient, delivering measurable savings and performance improvements.

• Design for Manufacturability: Early collaboration ensures that part geometry, bend radii, and weld joints align with real-world fabrication methods. By optimizing around available processes, machine capabilities, and material behavior, parts transition from model to metal with fewer adjustments and higher first-pass yield.
• Material & Yield Optimization: Engineers can nest parts efficiently, recommend standard material gauges, and minimize waste. Our design engineers routinely maximize sheet yield, keeping raw material costs low while meeting strength and performance targets.
• Preventing Rework & Delays: Identifying manufacturability pitfalls before production eliminates late-stage redesigns and production stoppages. Even small adjustments, such as standardizing hole sizes or modifying bend reliefs, can prevent large-scale rework and reduce assembly complexity.
• Reduced Assembly & Finishing Costs: Integrating alignment features, such as tabs and slots, or simplifying weld joints can dramatically shorten assembly time and improve fit-up precision, thereby reducing both labor hours and quality-control rework.
• Improved Reliability: By anticipating stress points and forming behavior during the design phase, engineers ensure stronger parts that perform consistently under load, reducing failures and long-term maintenance costs.

Early Engineering in Action

The real value of early engineering support becomes clear when you look at how it changes outcomes on the shop floor. By refining geometry, material usage, and assembly strategy before production begins, we reduce waste, shorten lead times, and enhance product reliability. The examples below show how our talented engineers turn design insight into measurable cost savings and manufacturing efficiency.

Reducing Scrap with Strategic Bend Reliefs

Bend reliefs are small cuts at the ends of bend lines that prevent cracking or material distortion during forming. Without them, parts can tear, deform, or fail inspection, which results in costly scrap and downtime. Early engineering ensures reliefs are correctly placed and dimensioned to the material thickness and bend radius, reducing stress concentration and preserving part integrity.

Real-World Example of Fabrication and Engineering: When a customer’s enclosure design placed flanges too close to cut-outs, Lock-Ridge’s engineering team added precision bend reliefs to prevent cracking during press brake forming. This minor adjustment eliminated a recurring defect that had been causing a 10 percent scrap rate, saving both material and rework time while maintaining cosmetic quality.

Reducing Labor Requirements with Slot-and-Tabs

Slot-and-tab features allow parts to self-locate and interlock during assembly. Early engineering can identify where tabs and slots can replace welding or separate fasteners and incorporate these into the sheet metal flat pattern and bending sequence. By replacing manual fixturing or extensive welding setups, they reduce assembly time, improve alignment, and enhance repeatability.

Real-World Example of Fabrication and Engineering: For a complex multi-panel housing, Lock-Ridge engineers introduced a slot-and-tab layout that allowed panels to snap into position prior to welding, rather than relying on inconsistent clamps and fixtures for alignment. By engineering tabs and slots into the design, parts align consistently, reducing distortion, setup time, and fixture costs. The improved alignment cut assembly time by 30% while enhancing weld quality, resulting in lower production costs.

Reducing Material Cost with Panel Stiffening

Panel stiffening enhances the structural rigidity of sheet metal components by including design features such as flanges, ribs, or hems. These techniques enable the use of lighter or thinner material and fewer support frames while reducing deformation under load. Early engineering can leverage this to reduce cost. Proper stiffening allows for the use of lighter gauge material and less internal bracing, thereby reducing both material and welding costs.

Real-World Example of Fabrication and Engineering: During prototype review for a large sheet-metal cover, Lock-Ridge engineers identified material inefficiencies that risked compromising performance and inflating costs. By refining the design with panel stiffening ribs and hems, we were able to use thinner steel, which reduced material costs and assembly weight. We maintained structural stiffness while reducing total material use by 15 percent, resulting in an immediate cost reduction without compromising strength or appearance.

Where Fabrication and Engineering Align

At Lock-Ridge Tool, fabrication and engineering operate as one integrated process, from design and prototyping through laser cutting, forming, machining, and final assembly. Every project benefits from a seamless handoff between disciplines that delivers faster production, higher precision, and measurable savings over the full lifecycle of the part.

Ready to optimize your next build? Contact Lock-Ridge Tool’s engineering team to see how early design collaboration can reduce total cost and accelerate production from prototype to finished product.
